22 Bantam reels. Please swap the SVS Infinity brake holder from stock spool, using SVS puller 6P listed on the product page.
Ultra light weight spools, 7.8g of 33R, 8.8g of 58R instead of 12.1g of stock spool, accelerate fast with light rigs.
33R 3.3mm deep, 0.285mm-65m/72yds, fine for 5g 3/16oz or heavier
58R 5.8mm deep, 0.310mm-75m/83yds, fine for 7g 1/4oz or heavier
Avail shallow spool for old ABU 5000C 5001C reels in 60's and 70's with flat side plates and fixed spool shaft on spool. Does not fit to 5000C with palming cup, 5000C with a little popping gear plate, 5000 with bronz bushing or 5500C high speed reels. 0.285mm-110m
Avail shallow spool for old ABU 5500C reels in 70's with flat side plates and fixed spool shaft on spool. Does not fit to 5500C sold in 80's or later. Difference is at the genuine spool, and 70's spool has silver plates on both sides, but 80's doesn't have them and it is black spool wall. 0.285mm-110m
Avail super shallow spool for old ABU 5500C reels in 70's with flat side plates and fixed spool shaft on spool. Does not fit to 5500C sold in 80's or later. Difference is at the genuine spool, and 70's spool has silver plates on both sides, but 80's doesn't have them and it is black spool wall. 0.285mm-75m
This shallow SV spool is to improve casting performance of Daiwa Alpahs SV 800 reels. Flat bottom, ultra light-weight 12g spool to improve casting performance especially for ultra light weight rigs 3g-7g 1/8-1/4oz. Casts great for heavier than 3g 1/8oz. 0.285mm(US10lb)-55m(60yds)
This modified Magforce Z Boost spool has 0.8mm longer brake rotor installed to emit more brake force than stock spool, and you may cast from 14g 1/2oz easy and long. Fits to Daiwa 21/22 Steez A TW HLC reels.
You may cast 3g. Ultra light weight 3mm deep super shallow tuning spool for Shimano 17Scorpion BFS, 21 SLX BFS, 21Curado BFS. CNC machined ESD extra strong duralumin spool with titanium center shaft. 32mm dia. 4.97g. Stock spool weights are Scorpion BFS spool 8.9g, SLX BFS 9.2g. Not for 17Conquest BFS or 16Aldebaran BFS.
Please insert pinion peek bar accompanied to pinion gear.
You may cast 3g. Ultra light weight 2.5mm deep super shallow tuning spool for Shimano 16Aldebaran BFS. CNC machined ESD extra strong duralumin spool with titanium center shaft. 32mm dia. 4.50g. Stock spool weight is Aldebaran BFS spool 7.2g. Not for 17Conquest BFS or 17Scorpion BFS. Please insert pinion peek bar accompanied to pinion gear.
This spool extends casting distance by reducing brake force at the later half in casting. Fits to Daiwa 1000, 1012, 1025 and 1016 reels, T3(all models) and etc. Flat bottom, light-weight 15g spool to improve casting performance especially for relatively heavy rigs of 10g-28g 3/8-1oz. G1 grade duralumin. In MAGFORCE-Z Boost brake, rotor will pop out far only at the beginning of casting to prevent backlash, and then it retracts to the middle to reduce brake to add casting distance. The second half spring is 4 times stronger than the first half to do the trick. Compared to SV Boost spools, this Magforce-Z Boost spools have more weight, and it is more suitable for heavier rigs. You may cast long distance without fear of backlash with this spool. Casts great for heavier than 7g 1/4oz. 0.330mm(US12lb)-100m(110yds)
Ultra light weight ultra shallow spool for Shimano 22 Aldebaran BFS for the ultimate finesse performance. You may easily cast from 1.5g with this spool.
2.2mm deep, 4.7g, line capacitiy 0.148mm(JP4lb)-57m, 0.165mm(JP6lb)-38m
(genuine spool 6.7g, 0.235mm-45m)
Please add magnets if you feel you need more brake force. Magnets are listed below of this page.
Fits to Daiwa 15XX bait casters, including Daiwa 15Zillion TW1516. It also fits to Daiwa 2006-2009Zillion TWS100 export reels. This spool is to cast the longest for heavier than 1/2oz rigs. The brake rotor spring is 4 times stronger than regular spools, making it emitting far less brake force than regular spools. G1 duralumin material is employed. Spool dia 36mm, weight 14g, 0.330mm(JP16lb, US14lb)-100m(110yds).
This is the replacement spool holder on Daiwa SV reels and SV spools sold from 2013 to 2019. It is a cam at the brake rotor base, to push out the brake rotor when it is twisted by magnetic force. Its older version in black tend to get stuck with rotor cam, or to break in time at its very thin posts.
This white one is reinforced parts to replace the black spool holder. Later than 2020 year model SV reels seem to have new black cam in better design.
The C clip holding rotor may be removed by 2 flat head scerw drivers. You'll surely need a tweezers to set it back, to hold a washer in position and to set the C clip in the groove. C clip and a washer are pushed by a spring, and they jump out. Please take care.
G1 (air craft grade) duralumin heavy duty spool for Daiwa 1500 sized reels. This HD spool has fixed brake rotor to emit stable brake force in casting. The brake is great for bulky rigs like swim baits, large deep divers and spinner baits. LIne capacity JP20lb(0.370mm, US14lb)-100m(110yds), 15g, 36mm dia.
G1 (air craft grade) duralumin spool for Daiwa 1500 sized reels. This genuine spool has moving brake rotor to automatically adjust brake force in casting. The brake system is great to prevent backlash for wide range of rigs. LIne capacity JP20lb(0.370mm, US14lb)-100m(110yds), g, 36mm dia.
This spool extends casting distance by reducing brake force at the later half in casting. Fits to Daiwa 1000, 1012, 1025 and 1016 reels, T3(all models) and etc. Flat bottom, ultra light-weight 11g spool to improve casting performance especially for ultra light weight rigs 3g-7g 1/8-1/4oz. G1 grade duralumin. In SV Boost brake, rotor will pop out far only at the beginning of casting to prevent backlash, and then it retracts to the middle to reduce brake to add casting distance. The second half spring is 4 times stronger than first half to do the trick. Casts great for heavier than 3g 1/8oz. 0.330mm(US12lb)-80m(90yds)
Ultra light weight shallow spool for Shimano 20 Metanium and 22 Metanium Shallow for the ultimate finesse performance.
20MT24R, 2.4mm deep, 7.5g, line capacitiy 0.205mm-70m
20MT42R 4.2mm deep, 7.8g, line capacitiy 0.235mm-90m
(genuine spool 14.1g, 0.285mm-100m)
SVS Infinity brake holder is not coming with this spool, and please swap it from stock spool. Avail SVS Infinity Puller is useful to do the job. You may also use this spool with MB-20MT magnet brake system. Both are listed on this page below.
Avail shallow spool for old ABU 5000C 5001C reels in 60's and 70's with flat side plates and fixed spool shaft on spool. Does not fit to 5000C with palming cup, 5000C with a little popping gear plate, 5000 with bronz bushing or 5500C high speed reels. 0.285mm-110m
Avail super shallow spool for old ABU 5000C 5001C reels in 60's and 70's with flat side plates and fixed spool shaft on spool. Does not fit to 5000C with palming cup, 5000C with a little popping gear plate, 5000 with bronz bushing or 5500C high speed reels. 0.285mm-75m
You may cast 2g. Ultra light weight shallow tuning spool, 3mm deep spool for SLPW 23Millionaire Air, Daiwa 20Alphas Air TW, 21Gekkabijin Air TW, 22Silver Creek Air TW, 20Alphas Air, 19 Steez Air TW. 28mm dia. 3.8g (measured without ball bearing). Spool shaft end has SIC ball to spin fast. Shaft is made of titanium. Fixed brake rotor offer stable brake. Brake is about 35% less than that of stock spool.
You may cast 3g. Ultra light weight super shallow, 3mm deep, tuning spool for Daiwa 19Alphas CT700, 19Steez CT700 and 19Millionaire CT700. Spool shaft end has SIC ball to spin fast. Shaft is made of titanium. 30mm dia. 4.3g(measured with ball bearing)
Fixed brake rotor offer stable brake.
21 Calcutta Conquest 100 spare spool, with brake holder and brake blocks, ready to use. Also fits to 24 Conquest 30/31. Line capacity 0.285mm(US10lb)-100m(110yds), about 30% more than that of 24 Calcutta Conquest 30/31.
This is the replacement spool holder on Daiwa 21Zillion SV TW reels, which has SV Boost brake system. And it also fits to SV Boost spools sold from 2021 and after. It is a cam at the brake rotor base, to push out the brake rotor when it is twisted by magnetic force.
ABU 4500C, 4600C Ultra Cast model (spool shaft separates from spool body). Not fitting to low profile Ultra Mag in 80's like XLT.
Super light weight 9.8g, instead of 15.1g of stock spool. Extra strong duralumin spool.
4530UC2 0.235mm(US6lb)-50m/55yds
Please use the small parts (2 ball bearings, a washer, brake holder and white spool gear) from stock spool or sold below separately. Casts great from heavier than 4g
