Tuning handles for Daiwa and ABU bait casting reels
Handles on this page accept 8mm main shaft, which is employed on Daiwa and ABU bait casters.
Shimano Conquest, TE and TE-GT in 300/301, 400/ 401 have 8mm shaft, and handles on this page fit. Please purchase M8 hooded nut. Shimano stock nut is 11mm hex size and won't fit with the retainers coming with handles. *1 For Daiwa with 12mm handle screw models, please choose SCR model or purchase either of DS 10mm screw for ZPI handles, or Handle Screw 10mm for other handles. 12mm screws are on: Steez EX100XS/HS, Ryoga JDM, Daiwa-Z JDM, Zillion J Dream, Zillion PESP and etc. Handle is fastened by handle screws with 12mm heads, which do not fit to 10mm retainers of tuning handles.
If you are not sure if the tuning parts fit to your tackle, please Email Jun Please refer to here as well. How to change knobs, knob compatibility
DRT Varial handle is full machined heavy duty handles for big baits. This 110mm version has large DRT flat knobs. Handle plate is quite thick 6mm at center to offer SOLID cranking. Stiff rubber knobs are large enough to grip firmly. Accept straight star up to 27mm radius, and sway back star drags. DRT Handle center nut is not included, and please purchase at least one or you may not fit the handle to reels. You may fit DRT flat knobs to this handle. Comes with fitting plates in 7mm and 8mm, wrench for center nut. Made in Japan
The latest high-end carbon material, TORAYCAT1100G employed handle. Fits to reels with sway back drag wheel. Daiwa Steez, Zillion, Alphas, Tatula and etc. Comes with 4 ball bearings, 2 retainers for 10mm and 12mm hex, and a screw. Accept Daiwa S knobs.
DRT Varial single power handle for giant swim baits of over 12". Knob is single flat DRT knob. You may change the radius of the handle by changing the direction of the center components from 70mm to75mm (diameters from 140mm to 150mm) to suite the best for loads. Counter balancer is adjustable for distance to balance. DRT Handle center nut 140-150 is not included, and please purchase at least one or you may not fit the handle to reels. Comes with washers and the wrench for the center nut. The wrench cover with DRT logo on the photo is not included to this kit, or it is not sold separately.
The latest high-end carbon material, TORAYCAT1100G employed handle. Fits to reels with sway back drag wheel. Daiwa Steez, Zillion, Alphas, Tatula and etc.
Comes with 4 ball bearings, 2 retainers for 10mm and 12mm hex, and a screw.
Accept Daiwa S knobs.
The latest high-end carbon material, TORAYCAT1100G carbon fiber employed handle with special color knobs in Move purple/green mazziora. Fits to reels with sway back star drags. Daiwa Steez, Zillion, Alphas, Tatula and etc.
100mm light weight duralumin handle with EVA knobs for power cranking.
Comes with retainer and screw. Fits to all Daiwa and ABU bait casters.*1
Handle frame is sway back and requires sway back star drag, or star will contact to the handle.
100mm light weight duralumin handle with large knobs for power cranking.
Comes with retainer and screw. Fits to all Daiwa and ABU bait casters.*1
Handle frame is sway back and requires sway back star drag, or star will contact to the handle.
You may change the knobs. 2 ball bearings installed (1 ball bearing per 1 knob)
70-75mm single power handle with counter balancer. You may change length 70 or 75 by changing the direction of center spacer. Machined aluminum frame and EP41mm dia titanium knob. Matches with sway back star drag reels, and straight star of up to 27mm radius.
Daiwa B1 SCR fits to Daiwa with hex head screw center nuts, like Steez, Zillion TW, and Tatula HD. Daiwa B2 fits to 15Saltiga 10-35 Japan models (not listed and please email for them) It would take about a week to be shipped
65-70mm single power handle with counter balancer. You may change length 65 or 70 by changing the direction of center spacer. Machined aluminum frame and EP41mm dia titanium knob. Matches with sway back star drag reels, and straight star of up to 27mm radius.
Daiwa B1 SCR fits to Daiwa with hex head screw center nuts, like Steez, Zillion TW, and Tatula HD. Daiwa B2 fits to 15Saltiga 10-35 Japan models (not listed and please email for them) It would take about a week to be shipped
60-65mm single power handle with counter balancer. You may change length 60 or 65 by changing the direction of center spacer. Machined aluminum frame and EP37mm dia titanium knob. Matches with sway back star drag reels, and straight star of up to 27mm radius.
Daiwa B1 SCR fits to Daiwa with hex head screw center nuts, like Steez, Zillion TW, and Tatula HD. Daiwa B2 fits to 15Saltiga 10-35 Japan models (not listed and please email for them) It would take about a week to be shipped
Livre Crank 110Best handle for Tai-rubber with Shimano Conquest 200, 300.
110mm swept handle with machined aluminum frame and titanium knobs. Matches with sway back star drag reels, and straight star of up to 27mm radius.
Daiwa B1 SCR fits to Daiwa with hex head screw center nuts, like Steez, Zillion TW, and Tatula HD. It would take about a week to be shipped
Livre Crank 120Best handle for Tai-rubber and super light jigging, SLJ, with Shimano Conquest 200, 300.
120mm swept handle with machined aluminum frame and titanium knobs. Matches with sway back star drag reels, and straight star of up to 27mm radius.
Daiwa B1 SCR fits to Daiwa with hex head screw center nuts, like Steez, Zillion TW, and Tatula HD. It would take about a week to be shipped
100mm swept handle with machined aluminum frame and titanium knobs. Matches with sway back star drag reels, and straight star of up to 27mm radius.
Daiwa B1 SCR fits to Daiwa with hex head screw center nuts, like Steez, Zillion TW, and Tatula HD.It would take about a week to be shipped
100mm long power handle with power knobs. Swept, machined aluminum frame, titanium knobs
All Daiwa and ABU bait casters.*1
No sway back star drag needed. Please specify right, left or SCR. For Daiwa reels with handle locking screw, instead of nut, should choose SCR. For Ex., Ryoga, Z, Zillion special models, Steez, Zillion TW and etc. Suitable for Daiwa 300-ABU6500 sized reels.
90mm swept, machined aluminum frame, titanium knobs
All Daiwa and ABU bait casters.*1
No sway back star drag needed. Please specify right, left or SCR. For Daiwa reels with handle locking screw, instead of nut, should choose SCR. For Ex., Ryoga, Z, Zillion special models, Steez, Zillion TW and etc.
Sway back, Extra Super Duralumin(ESD) handle frame fitting to 8mm shaft reels, almost all Daiwa/ABU bait casters. It is very strong and super light weight. 85, 90, 95, 100, 105mm, weight 13.2g 100mm. Color: Champaign gold, gunmetal, black. Fits to ABU and Daiwa with sway-back star drags. Accept both Daiwa S and Shimano A knobs. 85mm and 90mm have light-weight ESD duralumin knob shafts. 95-105mm handles have sturdy titanium knob shafts. Comes with a retainer in the same color as handle frame, and a retainer screw.
Machined 4mm thick frame made of air craft grade alloy, Extra Super Duralumin, installed with machine-cut titanium knob shafts, the Avail Power Handle T4S is the piece of craftsman-ships with sturdiness. All Daiwa and ABU 1500-6600 bait casters. Comes with retainer and screw. 100mm, 110mm. Best suitable for ABU6500CS Rocket. Accept Daiwa S, Shimano A, knobs
55mm long single power handle with large T knob for Daiwa/ABU bait casters. Fits to Right hand reels. Comes with a nut(R), retainer and screw. Best for Millionaire 300 and ABU 6500/6600. Daiwa star wrench is required to turn nuts. For left hand reels, Daiwa Star Nut M8 Left is required.
55mm long single power handle with EVA knob for Daiwa/ABU bait casters with sway back star drag. 2 ball bearing installed. Fits both to Right hand reels. Comes with a nut (R), retainer and screw. Best for Millionaire 300 and ABU 6500/6600. Daiwa star wrench is required to turn nuts. For left hand reels, Daiwa Star Nut M8 Left is required.
Handle is swayed. Accepts sway back star drag, and straight shaped star drags of up to 23mm radius.
63mm long single power handle with 45mm dia large knob for Daiwa/ABU bait casters, and 00/15Shimano Conquest 300/400. 2 ball bearing installed. Fits to reels with 8mm shafts. Comes with two nuts (R and L) and cover cap. Best for Millionaire 300, ABU 6500/6600 and Conquest 400. Accepts sway back star drag, and straight shaped star drags of up to 50mm diameter, fine for most ABU 1500-6600 and Daiwa.
70mm long single power handle with 44mm dia large knob for Daiwa/ABU bait casters, and Shimano Conquest 300/400. 2 ball bearing installed. Comes with R nut and nut cover. Best for Millionaire 300, ABU 6500/6600 and Conquest 400/401. For left hand reels, Daiwa Hooded Nut M8 Left is required. Accepts sway back star drag and straight shaped star drags of up to 60mm diameter, fine for most ABU 1500-6600 and Daiwa.
DRT Varial handles are full machined heavy duty handles for big baits. Handle plate is quite thick 6mm at center to offer SOLID cranking. Stiff rubber knobs are large enough to grip firmly. Accept straight star up to 27mm radius, and sway back star drags. DRT Handle center nut is not included, and please purchase at least one or you may not fit the handle to reels. DRT replacement flat knob rubber is fitting to this 87mm handle. Made in Japan
Knob caps for DRT Varial handles. 23mm dia. This knob cap fits to the original knobs of Varial 95/100mm handles. Doesn't fit to the original knobs of Varial 87/110/117mm handles, which have 16mm dia knob caps.
You may fit DRT Slim/Fat knobs to Varial 87/110/117mm handles by installing this knob caps. 1pc in package.
